Dynacord V600:2 Трансляционный усилитель, 2x300 Вт.

Dynacord V600:2 - Трансляционный усилитель

Характеристики:

• ELECTRICAL
  • Total rated output power[1]: 600W
  • Number of channels: 2
  • Rated output power[1]: 2 x 300W
  • Output power: 4Ω / 8Ω / 70V / 100V
  • Maximum output power per channel (power sharing): 500W / 600W / 500W / 600W
• AMPLIFIER
  • 4Ω / 8Ω / 70V / 100V
  • Nominal Gain:(+6 dBu input sensitivity, LEVEL 0 dB): 27.0 dB / 30.0 dB / 33.2 dB / 36.2 dB
  • Signal to Noise Ratio (A‑weighted, ref. to rated output power, LEVEL 0 dB): > -100 dB / > 102 dB / > 101 dB / > 103 dB
  • THD+N (1/8 RATED OUTPUT POWER, 1 KHZ): < 0.1%
• CONNECTIVITY
  • Type: 1 x 6-pin Euroblock, 3.81 mm, male, parallel 1x RJ45 (AES72-1E)
  • Loudspeaker output: 2 x 4-pin Euroblock, 5.08 mm, female
  • Control port type: 1 x 5-pin Euroblock, 3.81 mm, male
• Signal processingInput Routing, Filter (24 dB/Oct.), Hi-pass 30/50/100/150 Hz, Lo-pass 150 Hz, Peak Limiter
• Power requirements100V to 240V, 50 Hz to 60 Hz AC
• Power consumption
  • Idle mode (ecoRAIL with no input signal): < 12W
  • Consumption at 1/8 rated output power: 115W
  • Standby mode (APD active): < 1W
• ProtectionsAudio limiters, high temperature, DC, HF, short circuit, back-EMF, peak current limiters, inrush current limiters, mains over/under voltage protection
• Notes[1] Test signal for max. output power according IHF-A-202 (Dynamic-Headroom, burst 1 kHz / 20 ms on / 480 ms off / low level -20 dB)
