Bettermaker Vacuum Stereo Passive Equaliser 2-канальный параметрический эквалайзер

Bettermaker Vacuum Stereo Passive Equaliser - 2-канальный параметрический эквалайзер

Характеристики:

• Maximum input level: +24 dBu (balanced with 48kΩ input impedance)
• Maximum output level: +22 dBu
• Output impedance: 120Ω (30Ω with HEAT activated - transformer balanced)
• Nominal audio level: +4 dBu
• Max LF boost: 15 dB (set to 100 Hz)
• Max LF cut: 16 dB (set to 100 Hz)
• Max HF boost: 18 dB (all frequencies) Low boost/cut frequencies: 20, 30, 60, 100 Hz
• High boost frequencies: 3, 4, 5, 6, 8, 10, 12, 16, 20, 28 kHz
• High cut frequencies: 5, 10, 20 kHz
• Control Resolution: 101 steps (Lo Boost, Lo Cut, Hi Boost, Bandwidth) & 34 steps (Hi Cut)
• Control Resolution in Quantize mode: 17 steps for all controls
• Output gain: +/- 8 dB (0.1 dB resolution; 1 dB in Quantize mode)
• Unit height: 2U
• Unit depth: 140 mm
• Unit weight without cables and PSU: 2.7kg
• AC power consumption: 18W (2W in standby, with included 100-240VAC power adapter)
• Shipping weight & dimensions: 3.5kg, 60x30x20 cm
